Design of modern smart meters, the selection of core hardware components directly determines metering precision, system stability, and long-term operational and maintenance (O&M) costs. As global energy grids transition digitally, electricity meters are no longer just billing tools; they have become critical nodes for energy monitoring and network security.

Details

Powering the Smart Grid: FR4PCB’s Next-Generation Smart Meter Chipset Solutions

As a leading provider of industrial electronic solutions, FR4PCB is committed to delivering a full-stack portfolio of chip assets for meter manufacturers, ranging from core metrology and main processing to non-volatile storage and efficient power management. We have established a rigorous component screening system tailored to the harsh environments of utility applications, ensuring that every chip can operate reliably over a lifecycle of 10 years or more.

Model / Part Number	Quantity	Package	Manufacturer / Brand	Application Description & Features
71M6513-IGTR/F	10,000	LQFP100	SILERGY/MAXIM	Polyphase Smart Meter SoC; 21-bit Δ-Σ ADC, 8051 core, integrated RTC and LCD driver; 0.5% precision.
71M6513-IGT/F	10,800	LQFP100	SILERGY/MAXIM	Three-phase energy metering SoC; 6-channel analog inputs, internal temperature compensation; suitable for industrial multi-phase meters.
71M6533-IGTR/F	30,000	LQFP-100	SILERGY/MAXIM	High-precision polyphase energy metering IC; supports multi-circuit measurement and integrated power management; designed for Smart Grid meters.
71M6533-IGT/F	17,280	LQFP-100	SILERGY/MAXIM	Three-phase energy metering chipset; performs measurement of voltage, current, power, and energy; supports SPI/UART.
PIC16F720-I/SS	16,000	SSOP-20	MICROCHIP	8-bit MCU; 10-bit ADC, LCD driver; suitable for main controllers in single-phase smart meters.
PIC16F720T-I/SS	32,000	SSOP-20	MICROCHIP	Low-power 8-bit MCU; integrated temperature sensor; suitable for battery-powered utility meters.
PIC16F721-I/SS	22,000	SSOP-20	MICROCHIP	Enhanced 8-bit MCU; 16-bit PWM, USART; optimized for encrypted data transmission in meters.
PIC16F721T-I/SS	68,000	SSOP-20	MICROCHIP	Low-power 8-bit MCU; internal LCD driver + RTC; ideal for IoT smart meters.
PIC16LF721T-I/SS	16,000	SSOP-20/21	MICROCHIP	Ultra-low voltage 8-bit MCU (1.8V–5.5V); specialized for solar-powered utility meters.
ATSAMG55J19B-MU	15,067	QFN-64	MICROCHIP	32-bit ARM Cortex-M4F; hardware crypto acceleration, ECC, and LCD driver; for high-end smart meters.
STM32L162RET6TR	38,000	LQFP64	STMicroelectronics	Low-power 32-bit MCU; integrated LCD controller and 12-bit ADC; supports remote AMR (Automatic Meter Reading).
STM32L162RET6	9,600	LQFP64	STMicroelectronics	32-bit ARM Cortex-M3; integrated RTC and temperature sensor; suitable for multi-functional meters.
ATSAMG55J19B-AUT	8,000	LQFP-64	MICROCHIP	32-bit ARM Cortex-M4F; supports CAN bus and Ethernet; for industrial meter data transmission.
R9A06G037GNP#AA0	18,000	QFN-64	Renesas	32-bit ARM Cortex-M3; 16-bit ADC, LCD driver; for main control in smart meters.
MB85RS256BPNF-G-JNERE1	26,000	TSOP-8	Fujitsu/KAGA/ROHM	256Kbit FRAM (Ferroelectric RAM); ultra-low power, high endurance; for critical meter data storage.
MR45V256AMAZAAT-L	20,000	TSOP-8	Infineon/Cypress	256Kbit FRAM; high reliability with power-fail protection; specialized for parameter storage.
FM25V02A-G(TR)	20,000	SOIC-8	Infineon/Cypress	256Kbit FRAM; high-speed SPI interface, wide temperature; for industrial data logging.
MB85RS512TPNF-G-JNERE1	30,000	TSOP-8	Fujitsu/KAGA	512Kbit FRAM; unlimited write cycles and rapid write speed; for meter event logging.
FM25V05-G	20,000	SOIC-8	Infineon/Cypress	512Kbit FRAM; low voltage operation, high data retention; suitable for multi-functional meter data storage.
MAX17504ATP+T	25,000	TDFN-14	MAXIM	Power management chip; high-efficiency synchronous step-down DCDC converter.
S2-LPQTR	30,000	QFN-24	STMicroelectronics	Sub-GHz wireless RF transceiver; for IoT, smart meter reading, and wireless communication.
STM32G0B0RET6	10,000	LQFP64	STMicroelectronics	32-bit ARM Cortex-M0+; cost-effective universal MCU; suitable for industrial control, meters, and home appliances.
MAX38888ATD+T	10,000	TDFN-14	MAXIM	Power management and battery backup manager; simplifies backup for low-power devices.
MAX9064EUK+T	30,000	SOT-23/SC70	MAXIM	Micro-power comparator IC with integrated reference; for temperature sensing, high-precision thermometry, industrial control, and instrumentation.
NJM45001VP1-TE1	30,000	HTSSOP24	JRC/NJR	High-performance operational amplifier / audio power amplifier; low noise; suitable for industrial control and consumer electronics.
STM32L486RGT6	30,000	LQFP64	STMicroelectronics	32-bit ARM Cortex-M4; low power with hardware cryptography; for high-end meter and IoT applications.
STM32L486RGT6TR	30,000	LQFP64	STMicroelectronics	32-bit ARM Cortex-M4; high security, artificial intelligence enabled terminal for smart utilities.
PIC16F15344-I/SS	30,000	SSOP-20	MICROCHIP	Low-power 8-bit MCU; for miniaturized control, smart metering, and sensor terminals.

Core Solutions and Product Portfolio
High-Precision Metrology Cores

The "soul" of an electricity meter lies in its measurement accuracy. FR4PCB offers industry-recognized, high-performance polyphase and single-phase metrology chips, ensuring CLASS 0.5S or higher metering accuracy across a wide load range:

The Polyphase Benchmark: The 71M6513-IGTR/F and 71M6513-IGT/F are ideal choices for industrial and complex residential meters.
Flexible Expansion Solutions: The 71M6533-IGTR/F and 71M6533-IGT/F offer superior linearity and dynamic range, meeting the demand of smart grids for complex power quality analysis.

Ultra-Low-Power and High-Performance Main Controllers (MCUs)

To handle the complex functionalities of smart meters, such as multi-tariff structures, remote communication, and anti-tamper logging, we provide a diverse range of MCU options:

8-Bit Entry-Level Applications: For meters with basic functionality and extreme cost sensitivity, the classic and stable PIC16 series, such as PIC16F720-I/SS and PIC16F720T-I/SS, is the ideal choice.
Enhanced Ultra-Low-Power: For applications requiring battery power (such as gas and water meters), PIC16F721-I/SS, PIC16F721T-I/SS, and the extreme ultra-low-power version PIC16LF721T-I/SS provide exceptional standby power consumption performance.
32-Bit Performance Cores: For advanced meters that need to integrate communication protocol stacks (such as DLMS/COSEM):

ATSAM Series: The ATSAMG55J19B-MU and ATSAMG55J19B-AUT provide superior processing capabilities with the ARM® Cortex®-M4 core.
STM32 Ultra-Low-Power Series: STM32L162RET6TR and STM32L162RET6 (based on Cortex-M3), alongside the more powerful STM32L486RGT6 and STM32L486RGT6TR (based on Cortex-M4), maintain high performance while optimizing battery life.
New Generation Benchmarks: The STM32G0B0RET6 (based on Cortex-M0+) and R9A06G037GNP#AA0 offer an excellent balance of cost-performance and peripheral integration.

High-Reliability Non-Volatile Storage

Smart meters must possess the ability to safely save billing data and event logs during a power outage and must withstand an extremely high number of write cycles:

FRAM (Ferroelectric RAM): For applications requiring instant, unlimited write capability, we recommend our highly integrated solutions:

256Kbit: MB85RS256BPNF-G-JNERE1 and MR45V256AMAZAAT-L.
512Kbit: MB85RS512TPNF-G-JNERE1.

Cost-Effective Solutions: Universal 8-bit controller solutions, such as PIC16F15344-I/SS, often integrate ample high-reliability Flash/EEPROM internally, suitable for data retention in smaller-scale meters.

Efficient Power Management and System Monitoring

Utility equipment demands extreme efficiency and reliability:

High-Efficiency Converters: The MAX17504ATP+T provides compact, low-power DCDC conversion, minimizing internal heat generation in the meter.
Backup Power Management: For scenarios requiring emergency data upload at the moment of power loss, the MAX38888ATD+T backup power manager is critical for data protection.
System Monitoring and Comparison: The MAX9064EUK+T nanopower comparator and NJM45001VP1-TE1 op-amp are used for fine-grained anti-tamper detection and sensor signal conditioning.
Status Indication: The S2-LPQTR low-power status indicator module is convenient for field maintenance personnel to quickly diagnose the operating status of the meter.

Targeted Scenarios and Application Cases

FR4PCB's chipset solutions are widely deployed in the following smart utility sectors:

Residential Smart Energy Management: Combining 71M6533 metrology with STM32L series MCUs to achieve fine-grained measurement and upload of Home Energy Management (HEM) data.
Industrial Complex Power Grids: Utilizing 71M6513 and MB85RS512 FRAM for high-power, high-frequency write operations to ensure data integrity.
Battery-Powered Applications (Water/Gas/Heat Meters): Relying on the ultra-low-power characteristics of PIC16LF and STM32G0 to meet the requirement of a 10-year deployment without battery replacement.

Why Choose FR4PCB?

Utility-Grade Reliability Assurance: We understand the rigorous demands of utility projects for long-term deployment (10+ years) and extreme temperature adaptability.
Supply Chain Security: Beyond providing high-performance chips, we leverage our global supply chain network to ensure sustainable material supply throughout the long life cycle of the project.
Deep Technical Integration: The FR4PCB technical team can provide circuit design consultation services, integrating everything from core Measurement to secure Communication.

Contact Us: If you are looking for high-precision, long-life smart meter core hardware, please visit our official website at https://www. fr4pcb.tech
