Home > All Products > Industrial 1000Mbps Switch Module > 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
1/1
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
Share:

5-port Gigabit PoE Switch Module

SKU:
0.0 (0)
0 Sold
$21.50 $0.00

LX-SG505 Industrial Unmanaged PoE Switch, equipped with 5 Gigabit Ethernet ports (Ports 1-4 support IEEE 802.3af/at standards), delivers 30W per port power supply with intelligent PD (Powered Device) detection. Specifically engineered to provide cable-free power and data transmission integration for terminals such as APs/IP cameras/intercom systems in harsh environments.

Key Features:

  1. Robust Industrial Design: Withstands extreme temperatures (-20°C~75°C) and vibration
  2. High-Power PoE Output: 30W max per port (IEEE 802.3at compliant)
  3. Smart Power Management: Auto-detects PD device types and power requirements
  4. Plug-and-Play Operation: No configuration required for immediate deployment
  5. Surge Protection: Built-in 6KV lightning protection for industrial environments
  6. Long-Distance Transmission: Supports PoE power delivery up to 100 meters
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Type:
    5-port gigabit
    5-port gigabit
    5 gigabit ports (4 with POE)
    5 gigabit ports (4 with POE)
Quantity:
Add to Favorites (0)
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
1/1
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • 5-port Gigabit PoE Switch Module
  • Description
LX-SG505 Industrial PoE Switch, featuring 5 Gigabit ports with intelligent power supply, enabling cable-free power and data transmission for terminals such as APs/IP cameras.Name 5-Port Gigabit Switch Module
Model LX-SG505
Standards IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af/at Standard POE Power Supply (Optional)
Protocol CSMA/CD
Filtering and Forwarding Rate Ethernet 10Mbps (half-duplex) / 20Mbps (full-duplex): 10Mbps: 14,880pps
Fast Ethernet 100Mbps (half-duplex) / 200Mbps (full-duplex): 100Mbps: 148,800pps
Gigabit Ethernet 2000Mbps (full-duplex), 1000Mbps: 1,488,000pps
Power Consumption Idle: 300mW@12VDC; Full Load: 3W@12VDC
Network Media 10Base-T: Category 3 or higher UTP (=100m)
100Base-TX: Category 5 UTP (=100m)
1000Base-T: Category 6 or higher UTP (<100m)
Number of Ports 5 x 10/100/1000MRJ45 Ports
Cascade All ports can be used as UP-LINK ports
Forwarding Mode Store-and-Forward
Temperature Operating Temperature: -20°C~50°C
Extreme Operating Temperature: -30°C~70°C
Storage Temperature: 40°C~85°C
Humidity Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
Backplane Bandwidth 10G
LED Indicators 1 x Power LED
10 x Green/Yellow Port Data LEDs
Product Dimensions (WxHxD) 836616mm
Power Supply Voltage Input: DC5-60V/1A
Input Method: Plug-in 2P Terminal Block, Pitch 3.96mm

LX-SG50 5-port Gigabit PoE switch module (strictly following industrial communication equipment technical specifications), combined with the 2025 trend of intelligent terminal power supply and high-density deployment requirements, presented in a modular structured manner:

I. Intelligent Power Architecture

1. Precision Power Engine

Parameter Specification Technical Breakthrough
Max. Port Power 30W (IEEE 802.3at compliant) Powers 4K IR dome cameras (28W)
Total System Power 120W (dynamic allocation) Supports 4 PDs + 10% redundancy
PD Detection Speed ≤0.3s Prevents non-standard PD damage
Power Efficiency 93% (vs. industry avg. 87%) Saves >$180/year/unit
Power Logic:

🏗️ II. Industrial-Grade Reliability

1. Extreme Environment Adaptability

Dimension Specification Field Validation
Operating Temperature -30℃~70℃ Steel mill high-temp operations
Protection Rating IP30 metal housing Dust/mechanical damage resistance
Lightning Protection 4KV (IEC 61000-4-5 certified) 0% failure in outdoor surveillance
Vibration Resistance 5Grms (EN 50155 compliant) Deployed in rail transit systems
Triple Safeguards:
✅ Short-Circuit Fusing: Response 60℃

📡 III. High-Density Deployment Scenarios

1. Typical Topology

Power Management:

Total load: 66W ( Redundancy: 54W reserved for surges

2. Legacy Building Retrofit Advantage

Traditional Solution LX-SG505 Solution Efficiency Gain
Dedicated power wiring Single Cat6 cable for data+power Installation cost ↓45%
Large electrical shaft space Wall-mounted compact design Space saving ↓80%
Multiple failure points (adapters) Centralized power management Maintenance efficiency ↑300%

🔧 IV. Technical Evolution

2025 Key Upgrades

Feature Enhancement Customer Value
PoE++ Support 60W/port via firmware upgrade Powers PTZ laser cameras
Auto Topology Mapping Device connection diagram generation Fault localization in 15s
Energy Efficiency Idle port consumption B1(WiFi 7 AP support 40W)
A --> B2(IoT sensor clusters)
B --> C[2026]
C --> D1(Type 4 PoE 90W compatibility)
C --> D2(Solar power interface)

Specification for heat dissipation deployment
Dense power supply mode: Port spacing usage (to avoid 1-4 ports being fully loaded continuously)
High temperature environment: When the temperature exceeds 50 ℃, the rated power is reduced to 20W per unit
Installation direction: Vertical wall mounted (heat dissipation efficiency ↑ 25% vs horizontal placement)
Actual test data: When operating at full load in a 70 ℃ environment, the surface temperature rise of the metal shell is ≤ 35 ℃ (competitor ≥ 50 ℃), ensuring a MTBF of 150000 hours.

Industry positioning: LX-SG505 redefines the PoE deployment standard for small and micro scenarios with "zero configuration intelligent power supply", becoming the preferred power supply hub for the three major fields of security renovation, intelligent buildings, and retail IoT by 2025.
