✅ 1. Ultra-Fast Delivery System
Global Fastest Response Chain:
⏱️ 24-hour delivery closed-loop (1h for material allocation + 8h for production + 4h for full inspection + 11h for logistics)
🌐 Global Direct Delivery Network: 12-hour delivery within Asia / 36-hour delivery to Europe and the US (DHL pre-clearance system for customs)
Cost-Disrupting Formula:
💰 0.10/cm² (for orders ≥50m²)
📉 CAS (Chinese Academy of Sciences) nano-modified LCP substrate ($10/m²) + cyanide-free immersion gold process → Total cost reduction of 65%
⚙️ 2. Performance Generation Gap Benchmarking
| Parameter | Industry 24h Services | Our Solution | Improvement |
|---|---|---|---|
| Maximum Layer Count | 4 layers | 8 layers | 100%↑ |
| Line Width/Spacing Precision | 75/75μm | 50/50μm | 33%↑ |
| Bending Life | 50K cycles | 300K cycles | 500%↑ |
| Impedance Control | ±10% | ±3% | 70%↑ |
Core Technologies:
🔧 Plasma-laser hybrid process: Circuit formation speed of 12 minutes/layer (compared to 120 minutes for traditional methods)
🛡️ Carbon nanotube-reinforced transition zone: Bending stress resistance >220MPa (verified through real-world testing with Huawei's rollable display)
🌐 3. High-Value Application Scenarios
Foldable Devices (accounting for 70% of orders):
📱 OPPO X6 rollable display: 0.22mm total thickness, 300K-cycle dynamic life (with a bending radius reliability of 99.99%)
📌 Femtosecond laser UDI code: Precision ±3μm, high-temperature resistance up to 400℃
📊 5. Free Empowerment Ecosystem
Design-to-Manufacturing Integration:
🛠️ ANSYS digital twin platform: Predicting structural failure points in advance (accuracy rate of 98.7%)
📐 Open Huawei/Apple DFM libraries: 213 design rules (avoiding 89% of rigid zone cracking risks)
Industrial Cluster Advantages:
🏭 Yangtze River Delta supply chain: 99% material arrival rate at the factory (through electrolytic purification technology)
⚡ Energy Consumption Disruption:
Plasma etching energy consumption of 0.5kWh/m² (compared to 3.5kWh for traditional chemical etching)
🤖 Unmanned Production:
Dark factory with a per capita output value of $420K/year (1/5 of the labor cost compared to European and American counterparts)
⚡ Structural Level:
Carbon nanotube grid reinforcement (fracture energy increase of 300%)
Micro-arc rigid-flex transition (stress concentration reduction of 80%)
We lead in PCB manufacturing with advanced processes like high-precision drilling, fine-line fabrication (min. 50μm line width/spacing), and multi-layer lamination, meeting high-end routing density needs for stable signal transmission. A strict quality system ensures over 99.5% yield via flying probe and AOI tests. Our expert R&D team offers tailored solutions, from material selection to complex circuit design.
We provide FR-4, high-frequency, metal-core, and flexible boards, each with unique properties for various applications. Mass-produce 2 - 30 layer PCBs for efficient signal and power management. Customize board size, hole diameter, surface finish, and functions to fit specific scenarios.
Optimized production and advanced management shorten cycles. We control delivery for double-sided PCBs within [X] days and arrange multi-layer PCBs flexibly. With large capacity and emergency response, we avoid delays. Real-time tracking keeps clients informed.
Cost-saving measures enable competitive pricing without compromising quality. Transparent quotes detail all costs. Our PCBs excel in price, quality, and delivery, enhancing clients' product competitiveness.
Our sales team offers pre-sales expertise. Technical support spans design to production. We handle after-sales issues promptly
and conduct follow-ups for continuous improvement.
