Core Material Performance and Certifications
- Dielectric Stability:
- RO4350B™: Dk=3.48±0.05 (10GHz), temperature drift -50ppm/℃ (-50℃~150℃)
- RO4830™: Dk=3.0±0.04 (millimeter-wave band), insertion loss < 0.29dB/cm@40GHz (2025 IMS measurement)
- Reliability Assurance:
- MIL-PRF-31032 certified: 1000 thermal cycles (-55℃↔125℃) without delamination
- Lead-free reflow soldering resistance 260℃×5 cycles, MSL1 moisture sensitivity level
-
Rapid Process and Key Technical Metrics
| Process Aspect |
Breakthroughs |
Industry Benchmark |
| Lamination Precision |
Dk gradient error ≤ ±0.02 (laser real-time monitoring) |
Traditional ±0.08 |
| Impedance Control |
±0.8Ω@40GHz (3D EM simulation) |
±3.5Ω (non-optimized design) |
| Microvia Machining |
Laser drilling error ≤ ±4μm (CO₂+UV laser) |
Supports 30μm HDI microvias |
-
Scenario-Specific Performance Data
- 5G Millimeter-Wave Base Station (28/39GHz):
- RO4830™ single-board power capacity 230W/m²@38GHz, phase consistency ±0.7° (2025 IEEE EPEPS)
- Hybrid FR-4 solution reduces cost by 32%, jitter delay 0.1ps/mm
- 77GHz Automotive Radar:
- RO4350B™ temperature-compensated detection error < 0.2m (-40℃~125℃)
- Azimuth resolution 0.07° (combined with RO4450™ prepreg)
- Satellite Ka-Band Array:
- Antenna efficiency > 88%, 50% lighter than Al₂O₃ ceramic substrates
- Cost Competitiveness:
- Hybrid solution reduces unit price by $30/m²
- 10-layer board mass production yield > 96% (CPK > 1.8)
⚙️ Technical Solution Recommendation
Typical Stack-Up Structure (5G AAU Antenna Board)
| Layer |
Material |
Thickness |
Function |
| Top |
RO4830™ |
0.2mm |
Millimeter-wave signal transmission |
| Bond |
RO4450™ |
0.1mm |
Ultra-low-loss interface |
| Core |
FR-4 TG180 |
1.6mm |
Mechanical support/cost control |
| Bottom |
RO4350B™ |
0.2mm |
High-frequency ground layer |
| Measured Performance: Insertion loss 0.27dB/cm@28GHz |
Impedance tolerance ±0.9Ω |
Phase error ±1.2° |
|
🌟 Core Value Summary
- High-Frequency Performance: 40GHz insertion loss < 0.3dB/cm, supports 79GHz radar
- Time Efficiency: 72-hour delivery for 10-layer boards (including full-parameter test reports)
- Reliability: Military-grade environmental adaptability (-55℃~150℃)
- Manufacturability: Compatible with FR-4 production lines, supports 30μm laser microvias
