I. Breakthrough in High-Frequency Hybrid Technology
Utilizing Rogers 4350B+FR-4 gradient lamination process, combined with ultra-low roughness copper foil (RTF≤0.8μm) and vacuum step lamination (tolerance ±1.5%), we achieve:
- Dielectric Constant Control: Dk variation ＜±0.02 (industry standard ±0.1), ensuring beam accuracy for 77GHz radar phased arrays
- Loss Tangent Optimization: Df≤0.003 @10GHz, reducing signal attenuation by 40% compared to traditional FR-4
- Thermal Stability: Z-axis CTE＜40ppm/℃ (-55℃~+260℃), withstanding satellite orbital temperature shocks
Application Validation: Delivered 1000+ automotive radar boards in Q2 2025, with insertion loss ＜0.08dB/cm in the 76-81GHz frequency band
II. Military-Grade Inspection Loop
- Design-Side Prediction
- HyperLynx 3D field solver simulation, impedance tolerance ±2% (industry ±10%)
- Automatic generation of 268 DFM risk checklists (including hybrid interface delamination warnings)
- Process Control
- Online laser aperture measurement (accuracy ±5μm)
- X-ray interlayer alignment (deviation ＜12μm)
- Terminal Verification
- 77GHz VNA testing: S21 insertion loss & phase jitter analysis
- MIL-STD-883H temperature shock (-65℃~+150℃, 1000 cycles)
III. Limited-Time Privileges (Effective from June 27, 2025)
| Privilege Type |
Technical Value |
Applicable Orders |
| Millimeter-Wave Design Guide |
Includes 5 hybrid stack impedance model libraries |
First-time orders of any amount |
| Expedited Channel |
24-hour delivery for 10-layer boards (including flying probe testing) |
Orders over $3000 |
| Free CT Scan for Satellite Boards |
Layer defect detection rate ＞99.99% |
Aerospace/military projects |
📊 Data Traceability and Competitive Benchmarking
| Parameter |
Our Capability |
Industry Average |
Advantage Margin |
| Impedance Control Tolerance |
±2% |
±10% |
↑400% |
| High-Frequency Lamination Dk Variation |
±0.02 |
±0.1 |
↑80% |
| 10-Layer Board Delivery Time |
24 hours |
5 days |
↑83% |
| First-Article Yield (30-Layer) |
99.5% |
92% |
↑8.2% |
Why choose us？
I. Superior Tech, Quality Assured
We lead in PCB manufacturing with advanced processes like high-precision drilling, fine-line fabrication (min. 50μm line width/spacing), and multi-layer lamination, meeting high-end routing density needs for stable signal transmission. A strict quality system ensures over 99.5% yield via flying probe and AOI tests. Our expert R&D team offers tailored solutions, from material selection to complex circuit design.
II. Diverse Products, Versatile Solutions
We provide FR-4, high-frequency, metal-core, and flexible boards, each with unique properties for various applications. Mass-produce 2 - 30 layer PCBs for efficient signal and power management. Customize board size, hole diameter, surface finish, and functions to fit specific scenarios.
III. Timely Delivery, Project Assurance
Optimized production and advanced management shorten cycles. We control delivery for double-sided PCBs within [X] days and arrange multi-layer PCBs flexibly. With large capacity and emergency response, we avoid delays. Real-time tracking keeps clients informed.
IV. Competitive Pricing, High Value
Cost-saving measures enable competitive pricing without compromising quality. Transparent quotes detail all costs. Our PCBs excel in price, quality, and delivery, enhancing clients' product competitiveness.
V. Thoughtful Service, High Satisfaction
Our sales team offers pre-sales expertise. Technical support spans design to production. We handle after-sales issues promptly
and conduct follow-ups for continuous improvement.
