Twin-node server PCB assembly

SKU:
0.0 (0)
0 Sold
$0.02 $0.00
High-density twin-node server PCB assembly. Dual 10-layer HDI design, 800W per node, 10Gbps direct interconnect. Supports -40°C to +85°C operation for edge computing and HPC applications.
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Type:
    SMT PCB assembly: 20 million points/day
    PCB manufacturing: 80,000 m²/month
Quantity:
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
1/1
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Twin-node server PCB assembly
  • Description

🔧 Detailed Technical Description

1. Dual-Node High-Density Architecture

  • 2x 10-Layer HDI PCBs: Features 0.2mm laser-drilled microvias (0.06mm annular ring) with 6+6 stack-up (Dk=3.9, Df=0.009 @6GHz). Each node supports 2x PCIe 4.0 x8 lanes (16GT/s) and 1x 10Gbps SFP+ direct interconnect (85Ω differential impedance, ±5% tolerance).
  • Shared Power/Thermal Core: 4-layer power plane sandwich (2oz copper per layer) with embedded heat pipes (copper-water phase change, 500W/cm² thermal conductivity) and graphene-enhanced thermal pads (18W/m·K). Reduces inter-node thermal coupling by 35% (Icepak simulation) under full load.
  • Signal Integrity Optimization: Backdrill stub elimination (0.05mm residual stub length) and AC-coupled capacitors (0.1μF, X5R dielectric) for eye diagram opening >75% (PRBS31 pattern, 1e-12 BER). Complies with OIF CEI-56G-VSR-PAM4 for node-to-node communication.

2. Power Delivery & Efficiency

  • 800W/Node Power Architecture: 8-phase digital VRM (98.3% efficiency @12V→1.2V, 100A/phase) with MLCC+polymer capacitor hybrid filtering (150μF total capacitance, ESR<0.3mΩ). Supports 48V/24V DC input (reverse polarity protection, 100V surge tolerance) and <0.5mVpp output ripple (Intel VR13.0 compliant).
  • Dynamic Power Scaling: Per-node PMBus control (TI UCD90160) with 0.1% voltage accuracy and 10μs response time for AVX-512 workload optimization. Reduces idle power by 42% (tested with Intel Xeon Platinum 8480+).
  • Energy-Efficient Cooling: Variable-speed dual-rotor fans (4000–12000 RPM, PWM control) with hydrodynamic bearings (<25dBA noise @50% load). Achieves 1200 LFM airflow at 0.15"H₂O static pressure (AMCA-certified).

3. Manufacturing & Reliability Engineering

  • Advanced PCB Fabrication: 10-layer HDI via-in-pad design (0.18mm laser-drilled blind vias, 0.05mm back-drilling tolerance) with low-loss Megtron 6 core (Dk=3.7, Df=0.005 @10GHz).
  • Precision SMT Assembly: 0201 component placement (±0.02mm accuracy, IPC Class 2) with 12-zone reflow oven (peak temperature: 260°C±1°C). 100% 5D AOI inspection (0201 component detection) and X-ray solder joint analysis (<0.3% voiding rate for BGA packages).
  • Rigorous Testing Protocols: HALT testing (-55°C to +125°C thermal cycling, 500 cycles) and HTRB (3,000 hours @85°C). Achieves >99.98% first-pass yield and 15-year MTBF (calculated via Telcordia SR-332).
